We are all curious about how the small and simple electric clippers we usually use work. What is the working principle of the American electric clippers? Follow the store below to find out. The working principle of American hair clippers
①The eccentric shaft installed on the motor is well matched with the slot of the upper blade holder. When the motor is running, an eccentric ring is generated. The eccentric ring makes the upper blade change into the upper blade to balance left and right, and reciprocate at an eccentric distance of 1.5. movement,” and achieved a cut effect.
②The adjustment of the upper blade can trim the length of the hair. It is to adjust the length of the hair by pulling the adjustment wrench, so that the spring and the upper blade are integrated with the spring fixing seat, and move up and down along the pulling direction. Features: The trimming length adjustment device is completely combined with the blade group, so that the upper blade and the fixed blade can vibrate freely in a balanced manner. There is a sliding plate with a spring and a wrench, and the lower knife is provided with a support seat, into which an elastic member is installed, so that the elastic member is connected with the upper blade in such a way that the upper blade is pressed to the fixed position under the pre-tightening force. The blade plane makes shearing motion. Advantages: Sensitive adjustment, simplified structure and reduced processing costs, the entire trimming length adjustment is fully integrated in the cutting edge group, and at the same time, the upper blade can be freely vibrated.
As a component of the cutter head group, the cutter blade group together with the trimming length adjusting device is successfully achieved as an independent component independent of the casing, and there is no longer any operating member for adjusting the trimming length on the casing, thereby simplifying the structure.
